Rega Neo turntable PSU 24V

Rega NEO PSU Netzteil für Plattenspieler

Important: The Rega NEO PSU power supply is compatible with the following Rega turntables: P3-24 / RP3 / Planar 3 2016 / RP6 / P5 / P7 / RP40 special edition / RP8 and any older model equipped with a Rega 24-volt motor conversion kit.

The Neo PSU is an advanced turntable power supply providing user controllable fine speed adjustment, advanced anti-vibration motor circuit and the convenience of electronic speed change. The Neo will make a welcome addition to any compatible Rega turntable by reducing motor noise, improving speed stability and rotational speed accuracy.
It is a welcome addition to all Rega models with which it can be used, these are P3-24 / RP3 / Planar 3 2016 / RP6 / P5 / P7 / RP40 special edition / RP8 and any older model equipped with our 24-volt engine conversion kit.

The Neo works with a quartz-stabilized digital signal processor as used in the RP10. This DSP generates from the clock signal a sinusoidal curve with the exact frequency required by the 24V drive to precisely maintain the plate speed. Its main features include an anti-vibration circuit, fine speed adjustment and electronic speed switching.

Using the same DSP (digital signal processing) generator found in the RP10 the Neo is built upon a high stability crystal. The Neo features an advanced anti vibration circuit, fine motor speed adjustment and the convenience of electronic speed change. The DSP generator will divide the accurate signal from the crystal to the exact frequency required to turn the platter at the selected speed whilst will producing a near perfect sinusoidal waveform to drive the 24v motor.

• Two-phase motor control 24V AC with electronic fuse
• Fine speed adjustment in steps of 0.01/min
• Power consumption 7.2 W
• Power supply: Rega PS1 with double pole Euro plug 230V, 50Hz, 0,07A, output 24V, 350mA AC

Rega Neo PSU Technical Specifications

• Output to motor bi-phase = 24 V AC protected by resettable fuse.
• Power consumption = 7.2 W
• Voltage = 24 V AC
• Power supply: Rega PS1 only.
• Speed control step size = 0.01 RPM.
• PS1 (EU - Euro 2 pin)
• Input 230 V ~ 50 Hz 0.07 A
• Output 24 V ~ 350 mA AC
