Isotek Sirius V5 filtered socket strip

Isotek Sirius V5 Filternetzleiste | 6-way | filtered socket strip

The new V5 Sirius is an ultra-high performance 16A power strip that utilises IsoTek's latest mains power cleaning technology. It protects and improves the performance of your audio or AV system. You will also find a System Link connection, which allows you to extend the existing 6 outlets whilst maintaining the star ground wiring using only one wall socket for the entire system. In addition, the easily resettable fuse system offers a considerable improvement over the standard glass fuses usually used due to an enlarged contact surface.

Technical data

• Suitable for all audio, AV or network-based systems
• Reduces radio frequency interference (RFI) by 45dB
• A centralised filter network eliminates common mode and differential mode interference
• 6 independent outputs prevent push-pull crosstalk (16 A / 3,680 W @ 230V)
• 54,000 A instantaneous short-circuit protection
• Star-shaped earth wiring
• Internal wiring made of multi-strand silver-plated 6N OFC copper with FEP dielectric
• Fuse system with reset button
• Wall bracket included in the scope of delivery
• System Link output for expanding the existing 6 outputs while maintaining star-shaped earth wiring
• EVO3 PREMIER connection cable included in the scope of delivery

Design
All outputs of the V5 Sirius are individually connected to the central filter network. None of the outputs are directly connected to each other, so there is no overlapping of the push-pull interference generated by the connected electronics from one output socket to the other.

IsoTek's System Link connection allows the existing 6 outputs to be extended while maintaining the star ground wiring and using only one wall socket for the entire system.

The V5 Sirius features a significantly improved high performance shunt filter network offering -23dB at 10kHz, -40dB at 100kHz and -60dB at 1MHz (reference 50ohm 20dB, this is far superior to the conventional design and ideal for combating common mode interference).

The unique combination of the delta filter topology in conjunction with a high current line suppression choke clears the power supply of both common mode and differential mode interference.

The V5 Sirius features KERP© (Kirchhoff's Equal Resistance Path), which ensures equal resistance and equal power output to all sockets.

The internal cabling has been specially developed to provide the highest standards of power supply. Pure 6n oxygen-free and multi-stranded copper conductors with silver coating ensure low resistance and high amperage. An FEP dielectric is used to protect the conductors, providing a low dielectric constant.

The extremely fast responding 54,000 amp protection system improves sound and protects valuable audio components from dangerous current surges and voltage spikes.

The easily resettable fuse system offers a significant upgrade over a standard glass fuse due to the increased contact area. Due to its electrical function, a standard fuse must have a very thin wire, this also applies to expensive gold-plated versions in audiophile quality.

A special, easy-to-install wall bracket system is supplied, allowing you to discreetly mount the V5 Sirius behind your audio system if required.
